ACE Toolboxes Logo

ACE TOOLBOXES

MACS Engineering are proud to offer our latest range of toolbox product – ACE Toolboxes!

In stock & Available For Immediate Supply!

Materials with Openbox Icon at MACS Laser Solutions

Materials

ACE Toolboxes & internal fit out modules are all constructed from 2.0mm, 5052 marine grade aluminium. Most applications for users of Macs Toolboxes are rigorous & harsh environments so the quality of these materials is integral to ensuring ACE boxes are built tough & will stand up to the job. Precision laser cutting is utilized to ensure cutting quality & consistency of the built product.

Design with Pencil and Ruler Icon at MACS Laser Solutions

Design

ACE Toolboxes use the DNA of MACS toolbox design utilizing features including triple fold door edges to ensure maximum weather resistance, base rails to provide clearance between tray body & toolbox as well as fully adjustable shelf rails to allow use for any operational requirement.

Finishing with Paint roller Icon at MACS Laser Solutions

Finishing

Hard wearing powder coat is used to finish the box, inside & out. We use 040 white powder coat which matches closely to most utes available on the market.


Standard Features with Check Icon at MACS Laser Solutions

Standard Features

Stainless steel locking T handles, rubber door seals, gas struts & 1 x narrow width adjustable shelf are included with all ACE toolboxes.

ACE Toolbox – ACE01

Part Number ACE01
External Length 1400mm
External Depth 600mm
External Height 890mm
Weight 50kg
Material 2.0mm 5052 marine grade aluminium
Lock Stainless steel drop-T lock
Finish Powder coat 040 white
Door Seal Triple fold door & lid with rubber seal
Gas struts Yes
Base Rails 3 x 40mm high base rails
Shelf Narrow with, prefitted on adjustable rails
Base Mounting holes & drain points

ACE Drawer Set – ACE20

Part Number ACE02
External Length 500mm
External Depth 450mm
External Height 550mm
Weight 18kg
Material 2.0mm 5052 marine grade aluminium
Latches Stainless steel spring bolts
Finish Powder coat 040 white
Drawer Slides Angle friction slides
Drawer 1 & 2 65mm deep
Drawer 3 & 4 140mm deep

ACE Narrow Shelf – ACE10

Part Number ACE10
Length 1320mm
Depth 490mm
Height 30mm
Weight 3kg
Material 2.0mm 5052 marine grade aluminium
Mounts Bolt on angle
Fitment Lower half position on the adjustable rails
Finish Powder coat 040 white

ACE Wide Shelf – ACE11

Part Number ACE11
Length 1320mm
Depth 390mm
Height 30mm
Weight 2kg
Material 2.0mm 5052 marine grade aluminium
Mounts Bolt on angle
Fitment Any position on the adjustable rails
Finish Powder coat 040 white

If you have any queries about how a MACbuilt solution can help you, please contact us on:

TELEPHONE

VISIT OUR SHOWROOM

2D Victoria St, Mackay, QLD

ACE Toolbox – Common Configurations

ACE Wide Shelf – ACE11 at MACS Laser Solutions

ACE Toolbox – ACE01
+
ACE Drawer Set – ACE20

ACE Wide Shelf – ACE11 at MACS Laser Solutions

ACE Toolbox – ACE01
+
ACE Drawer Set – ACE11
